Brief Introduction
LC fiber optical adapter also called LC fiber optical coupler, which is a device for detachable connection between optical fiber connector and optical fiber connector. There are many styles, mainly simplex adapter, duplex adapter and 4-core adapter. Our company’s LC adapter appearance must be smooth and clean. It has no oil, burrs, scars and crack. The color of adapter must be bright in good consistency,all parts of adapter can assembly well without difficulty, it should be easy and comfortable to plug in and pull out connector from adapters, the clip should be powerful..
Features
1.Modes：Single mode or Multimode.
2.Sleeve in high precision.
3.Low insertion loss.
4.Good repeatability.
5.Good interchangeability.
6.Easy installation.
7.Good temperature stability.
Applications
1.Optical fiber communication system.
2.Cable television network.
3.Optical fiber access network.
4.Video transmissions.
5.Test equipment.
6.LAN,WAN
Specifications
| Project | Values | ||
| Reference standard | YD/T 1272.1-2003 | ||
| Insertion loss | ≤0.2dB | ||
|
IL change absolute value | low temperature | Temperature: -40℃, Duration: 168 h | ≤0.2dB |
| high temperature | Temperature: 85℃, Duration: 168 h, Temperature change rate: 1℃/min | ≤0.2dB | |
| Hot and humid | Temperature: 40℃, Humidity: 90%~95%, Duration: 168h, Temperature change rate: 1℃/min | ≤0.2dB | |
| Temperature cycle | Temperature: -40℃ to + 85℃, Duration: 168h, Cycle times:21, Temperature change rate: 1℃/min | ≤0.2dB | |
| Repeatability | Insertion pull times:10 | ≤0.2dB | |
| Mechanism durability | Insertion times: 500 cycles | ≤0.2dB | |
| Tensile strength Of coupling mechanism | 68.6N/10 Minute | ≤0.2dB | |
| Pull-out force | ≤19.6.N | ||
| Flame resistance | UL94-V0 | ||
| Work temperature | -25℃～+75℃ | ||
| Storage temperature | -40℃～+85℃ | ||
There are many types of LC adapters. The size must be determined before purchase. The colors are green, blue, beige, purple, and turquoise. The core can be Simple, Duplex, 4-cores.
 | How to know the difference between LC Adapter One-piece and Welding? ①One-piece Type: This means that the adapter body is one piece and does not need to be welded. There is no welding line in the middle of the adapter, which is a good appearance difference. ②Welding Type: Also called split adapter in China. The body of the adapter is divided into two halves, and it needs the welding process of the welding equipment to form a complete adapter. |
| Fiber Optical Adapters Packing Usually, we use transparent plastic boxes packaging, which can protect the adapter very well, and very neat. As shown in the picture. |  |
 | Our Quality Control We use highly reliable testing equipment. Each product must pass 100% test to ensure that all the products are reliable, good consistency and meet the international standards. Here, you can see our equipments and test methods. Learn More... |
